Runva EWX9500 electric winch 12V 9500 lbs with synthetic rope

Description

Runva EWX9500 is a proven all-round winch for SUVs and pickups. It has a 3-stage planetary steel gearbox, an automatic brake and a series wound motor. This version comes with synthetic rope, which is lighter and safer than steel cable.

Specifications

• Rated line pull: 9500 lbs (4309 kg)
• Motor: 12V series wound, 4.6 kW input
• Gear ratio: 230:1, 3-stage planetary steel
• Brake: automatic
• Synthetic rope
• Drum: 63 x 223 mm
• Line speed: 6.0 m/min with no load
• Mounting bolt pattern: 254 x 114.3 mm (4 x M10)

Rated line pull is measured on the first rope layer on the drum. For safe use, keep the working load at about 80% of the rated pull.
